An exceptionally light cordless chainsaw for garden and property maintenance at home, and for processing horizontal timber. With STIHL quick chain tensioning and QuickStop Super chain brake. 1/4” PM3 saw chain for a fine cut and good cutting performance. Quiet, no ear protection needed.
The STIHL AK-System devices are so quiet you don’t even need ear protection.
LOW-MAINTENANCE AND EFFICIENT. Thanks to its compact design, low weight and high efficiency, the EC engine enables you to work in an energy efficient manner. This engine also has a long service life.
STIHL Chain Quick Tensioning (B)
The STIHL chain quick tensioning system (B) makes it very easy to tension the chain. Just release the sprocket cover and turn the knob to set the optimum tension. No tools needed.
QuickStop Super Chain Brake (Q)
The additional braking system for extra safety. Users can trigger the chain brake directly at the rear handle. The chain stops in seconds whenever the user lets go of the rear handle and whenever there is sufficiently strong kickback or when the front hand guard is activated. This unique safety feature ensures even more user protection in all working positions.
Toolless filler cap
The tank can be filled quickly and easily using the toolless filler cap.
The ergonomically shaped handle and rear control handle with comfortable soft-grip component ensure safe working in all operating positions.
The soft black component on the rear control handle ensure a safe and secure grip in any situation. The control lever must be released using the lock button on the side.
AL 101 charger
230 V. Compatible with STIHL AK and AP batteries. With charge-level indicator (LED). Cable tie with Velcro tape. Wall-mounting possible.
Technical specifications Value Charging current 1,6 A Charging time AK 10 1) 95 min Charging time AK 20 1) 180 min Weight 0,7 kg Power consumption 0,08 kW
Compact lithium-ion battery for the STIHL AK-System with a voltage of 36 V and a capacity of 144 Wh. Battery life depends on the device type. With charge level indicator (LED). Compatible with AL 101, AL 100, AL 300 and AL 500 chargers.
Technical specifications Value Battery weight 1,2 kg Rated voltage 36 V Battery cell technology Lithium-Ionen AK-System Battery energy content 1) 144 W·h
Compact lithium-ion battery for the STIHL AK-System with a voltage of 36 V and a capacity of 180 Wh. Battery life depends on the device type. With charge level indicator (LED). Compatible with AL 101, AL 100, AL 300 and AL 500 chargers.
Technical specifications Value Battery weight 1,3 kg Rated voltage 36 V Battery cell technology Lithium-Ionen AK-System Battery energy content 1) 180 W·h Battery life MSA 140 C-BQ 2) 45 min
|STIHL Oilomatic saw chain type||Picco Micro 3 (PM3)|
|Rated voltage||36 V|
|Weight 1)||2,5 kg|
|Sound power level 2)||94 dB(A)|
|Vibration level left/right 3)||3,4/3,2 m/s²|
|Rollomatic E, cutting length||30 cm|
|Battery Technology||Lithium-Ion AK-System|
|Battery run time with AK 10 4)||up to 15 min|
|Battery life AK 20 4)||up to 35 min|
|Battery run time with AK 30 4)||up to 55 min|
|Sound pressure level 5)||83 dB(A)|
1) Without battery, with bar and chain
2) K-factor according to DIR 2006/42/EC = 2.5 dB (A)
3) K-factor according to DIR 2006/42/EC = 2m / s ²
4) Battery life times are approximate and may vary depending on application
5) K-factor according to DIR 2006/42/EC = 2.5 (dB (A))
